Specifications

Brand: Bigmax

Charger Type: Smart SMPS Battery Charger

Battery Type: LiFePO4 Battery

Battery Voltage: 12V (4S)

Output Voltage: 14.6V DC

Rated Output Current: 5A

Charging Method: CC/CV (Constant Current / Constant Voltage)

Input Voltage: 100–240V AC, 50/60Hz

LED Indicator: Red (Charging), Green (Fully Charged)

Cooling System: Built-in Cooling Fan

Measured Output (No Load): 15V

Measured Temperature (4.5A Load): 41°C

Protection: Over Voltage Protection

Protection: Over Current Protection

Protection: Short Circuit Protection

High Frequency SMPS Design

Stable Output with Low Ripple

Compact and Lightweight Design

Suitable for 12V (4S) LiFePO4 Battery Packs
